ON-DEMAND CUSTOMIZATION
Comprehensive pendant light design and processes, efficient R&D,
and rigorous quality control
7-10-DAY RAPID PROTOTYPING
CUSTOMIZE NOW
COMPLETE PROCESS CHAIN, FLEXIBLY TAILORED TO CUSTOM NEEDS
Covering the process of lighting design—from metal fabrication and glass/crystal craftsmanship to composite & natural materials and electrical/optical systems. We can flexibly combine materials and surface-finishing techniques to suit each project scenario, balancing aesthetics with performance reliability.
EFFICIENT R&D AND
PROTOTYPING TO ACCELERATE
PROJECT DELIVERY
Our independent R&D and ceiling chandelier design teams support 3D modeling; samples can be delivered within 7–10 days, along with renderings, photometric reports, and packaging plans. Sample testing standards are aligned with mass production to ensure feasibility.
STRICT LIGHTING PRODUCTION STANDARDS TO ENSURE CONSISTENCY
Key dimensions and color are controlled with a 3D coordinate measuring machine (CMM) and a colorimeter (ΔE ≤ 0.5); plating thickness tolerance ±2 μm; gloss maintained at 70–90 GU. All process parameters are recorded for every batch to enable full traceability and eliminate batch-to-batch variation.
5 CORE PROCESSES
Precisely matched to different
pendant light materials and application needs
CHOOSE MATERIALS NOW
01
METAL PROCESSING
CNC cutting, laser bending, precision TIG/MIG welding, and casting/die casting—supporting the forming of complex structures.
02
SURFACE FINISHING
Electroplating (gold / brass / black nickel), PVD vacuum deposition, anodizing, and hand-brushed finishing, with color variation controlled to ΔE ≤ 0.5.
03
GLASS & CRYSTAL
Hand-blown glass, hot-bend forming, K9 crystal cutting, and Spanish alabaster processing—supports acid etching, sandblasting, and gradient effects.
04
COMPOSITES & NATURAL MATERIALS
Resin, acrylic, FSC-certified woodcraft/bamboo-rattan, fire-retardant fabric treatment, reinforced with an embedded metal framework.
05
ELECTRICAL & OPTICS
High-efficiency LEDs (≥110 lm/W, CRI ≥ 90), smart dimming (Triac/0–10 V/DALI/DMX), IP44–IP65 protection.
SCENARIO-BASED PROCESS SOLUTIONS
Targeted answers to core challenges like ultra-large dimensions and
high-corrosion environments.
| TYPICAL CHALLENGES | CUSTOM LIGHTING SOLUTIONS |
|---|---|
| LOAD-BEARING AND TRANSPORT CHALLENGES FOR OVERSIZED, LARGE CUSTOM CHANDELIER | Using a modular, lightweight structure with aluminum alloy replacing heavy metal parts, and a segmented, numbered design for easy installation; overall weight is reduced by 40%, lowering transport and hoisting risks. |
| CORROSION AND FADING OF LAMPS FOR CEILING LIGHTS IN COASTAL PROJECTS | Employ 316L stainless steel or copper substrates with PVD coating or epoxy powder coating; ≥240-hour salt-spray tested for effective resistance to corrosion in high-salt-mist environments. |
| COLOR CONSISTENCY CONTROL ACROSS PRODUCTION BATCHES | Create a color-swatch archive for each batch, with ΔE ≤ 0.5 as the color-difference control standard; perform centralized plating/coating by batch, and conduct lot-by-lot color-difference testing plus manual reinspection before shipment. |
| UNEVEN LIGHT DISTRIBUTION AND GLARE ISSUES | Employ a secondary-lens + diffuser stack to ensure consistent beam angle (deviation ≤ 5°), reduce glare (UGR ≤ 19), and improve light uniformity. |
| LARGE FOYER CHANDELIER — SEISMIC RESISTANCE & MAINTENANCE CHALLENGES | Equipped with dual safety cables to enhance seismic resistance; the electrical assembly uses a slide-out design with quick-connect terminals, so maintenance requires no full fixture disassembly—cutting labor time by about 50%. |
GET A SOLUTION
QUALITY CONTROL
8–12 h burn-in + salt-spray testing, with batch sample retention for traceability.
CHOOSE CUSLUX CUSLUX
END-TO-END TESTING & VALIDATION
Finished products must pass 8–12 hours of high-temperature burn-in (45–55°C), simulating long-term use to ensure stability.
PRECISE PERFORMANCE
CONTROL
Random checks for luminous flux and CCT achieve a 100% pass rate, ensuring every suspended ceiling lamp meets output and color-temperature tolerances. Appearance inspection follows strict criteria: no scratches, no visible color difference (ΔE ≤ 0.5), and smooth, burr-free welds.
FULL TRACEABILITY
SYSTEM
Batch production records document raw-material suppliers, process parameters, and test reports to support traceability. A standard reference sample is retained for each batch and compared with subsequent replenishment orders to ensure consistency in color and materials.
INNOVATIVE SPECIALTY PROCESSES，BALANCING AESTHETICS AND FUNCTIONALITY
Cuslux excels in complex structures
mixed materials, and aesthetic consistency
with continuous innovation
CUSTOMIZE NOW
DUAL-LAYER MIXED-MATERIAL SHADE
frosted glass inner layer + electroplated acrylic outer layer, creating a lightweight reflective effect—ideal for weight-sensitive hotel lobby installations.
SCREWLESS EXTERIOR
DESIGN
concealed snap-fit + magnetic fastening, balancing aesthetics with maintenance convenience.
MODULAR LIGHT
ENGINE
integrated heat dissipation and driver for quick swap-outs, reducing maintenance costs for overseas projects.
ECO-FRIENDLY PROCESSES, BUILT FOR
SUSTAINABILITY
Compliant with EU, Middle Eastern, and other
international environmental standards.
CUSTOMIZE NOW
ECO-FRIENDLY MATERIALS
Low-VOC coatings, lead-free plating systems, and wood/bamboo sourced from FSC-certified suppliers.
ENERGY-SAVING DESIGN
High-efficiency lamps for ceiling lights across the lineup; smart dimming systems can reduce energy consumption by 60%+ and comply with SASO (Middle East) energy-efficiency certification.
SUSTAINABLE PACKAGING
Recyclable molded pulp and biodegradable cushioning materials to reduce the carbon footprint of overseas shipping.
CORE EQUIPMENT ENSURES PROCESS
EXECUTION
With fully in-house workshops and specialized machinery,
we deliver high-quality production of custom lighting.
HARDWARE WORKSHOP
LASER WORKSHOP
ECO-FRIENDLY POLISHING WORKSHOP
SURFACE FINISHING WORKSHOP
ASSEMBLY WORKSHOP
CNC MACHINES
ACRYLIC ENGRAVING MACHINES
CUSLUX — CREATE YOUR LIGHT
NO DRAWINGS? NO PROBLEM , WE MAKE IT REAL
CUSTOMIZE NOW, CONTACT US ANYTIME
